  • Originally posted by Aaron Murakami View Post
    Please give a reminder on what you're pointing out.
    My post #782:

    http://www.energyscienceforum.com/sh...ll=1#post28385
    The Syncro Heresy

    Comment


    • Originally posted by Aaron Murakami View Post
      Ron, if you check the resistance between the input terminal of the wires you spliced in to the spark plug cables to the terminal in the boot that slips over the plug is relatively low and you use non-resistor plugs, they should work fine. What is that resistance by the way if you can measure it?

      The coil you have looks simple enough - basic autotransformer coil with the primary if that its the red and white wires on the input and the hv output has a common ground with the ignition coil, you should have an easy job. I don't see what the Street Fire or other common MSD will not work. If that red is the primary + and the white is the primary - , then it should work.



      You hook it up like that depending on if you have points (top) or an electronic pickup (bottom). That is the first step to get the plasma on your Toyota.
      Aaron,
      The plug wires from the red section are solid wire for a direct connection to the plug. I spliced into the original wires leaving the top section coming from the cap original to help reduce RF?? I was under the assumption that when I build the plasma unit I would need to connect directly to the plug? I did the wire modification to allow that without having all wire plug wires which I understand can cause RF problems with the computer, right?

      Comment


      • I can't enlarge the instructions to be able to read them?

        Comment


        • Originally posted by rokan View Post
          I can't enlarge the instructions to be able to read them?
          Here's the full PDF http://documents.msdperformance.com/5520.pdf
          Aaron Murakami





          You never change things by fighting the existing reality. To change something, build a new model that makes the existing model obsolete. ― Richard Buckminster Fuller

          Comment


          • Connection to the top of each Spark Plug

            Originally posted by Aaron Murakami View Post
            Thank you for sending that!
            Ok, now I understand that hookup but I also thought we needed to connect the extra strong spark directly to the top of each non-resistor plug to get plasma?

            Comment


            • Originally posted by rokan View Post
              Thank you for sending that!
              Ok, now I understand that hookup but I also thought we needed to connect the extra strong spark directly to the top of each non-resistor plug to get plasma?
              When you hook up the MSD/CDI, you are already getting a stronger spark at each plug - from coil, thru distributor directly to each plug.

              After the MSD/CDI is hooked up, then you add diodes. 4 of them.

              If you're coil isn't suitable for capacitive discharge, I'd recommend this one: https://www.amazon.com/gp/product/B0...SIN=B002Q363XM

              After getting the cdi/msd hooked up, post your results and then we can diagram the diodes to the top of the plugs. That will be super easy.
              Aaron Murakami





              You never change things by fighting the existing reality. To change something, build a new model that makes the existing model obsolete. ― Richard Buckminster Fuller

              Comment


              • A lot of work was necessary in order to support the Plasma engagement.

                Here are my first impressions:

                Trying to lean the fuel mixture, it is possible to intervene to the time the injectors are functioning.

                "Using a stock file from a 1992 G60 Passat syncro, and ECU temperature of 87 deg C, an IAT of 32 deg C and a battery voltage of 14, I get the following results adjusting the CO pot value:

                800 RPM at 37.5 mbar:

                CO pot setting vs Inj PW

                0 ; 3.102 ms
                200 ; 2.620 ms
                400 ; 2.540 ms
                495 ; 2.480 ms <-- value where fuel is neither added nor subtracted
                600 ; 2.416 ms
                800 ; 2.328 ms
                1000; 2.254 ms
                1200; 2.202 ms
                1400; 2.156 ms
                1600; 2.120 ms
                1800; 2.088 ms
                2000; 2.062 ms

                6300 RPM at 175 mbar:

                CO pot setting vs Inj PW
                0 ; 9.146 ms
                200 ; 9.088 ms
                400 ; 9.042 ms
                495 ; 9.030 ms <-- value where fuel is neither added nor subtracted
                600 ; 9.006 ms
                800 ; 8.984 ms
                1000; 8.960 ms
                1200; 8.950 ms
                1400; 8.938 ms
                1600; 8.926 ms
                1800; 8.914 ms
                2000; 8.904 ms

                These values would only come into play when the ECU is in open loop, otherwise the O2 sensor takes over.



                http://forums.fourtitude.com/showthr...ng-copot/page2 "


                In my system the limit is the setting at 1900 Ω.

                By doing this adjustment, (at 1900 Ω), I am observing the following phenomena:

                1) Plasma on/off and the needle of the tachometer jumps, just a little bit, so the system affects the operation. (This is at any fuel adjustment).

                2) The engine's temperature remains on the same level as in the normal fueling. (The normal value is at about 490-500 Ω).
                (This is checked only under very light duty, since I haven't the time to check it under normal or heavy operation).

                3) There is a substantial drop in the performance of the engine, especially at the high revs.

                4) The first measurements with the on board trip computer saw an, almost, vertical slope in the reduction of the consumption.

                Saying these, the only point for anxiety is the drop in the performance.


                Any thoughts?
                Last edited by Hellenic Vanagon; 05-18-2018, 08:42 AM.
                The Syncro Heresy

                Comment


                • Just in the case you know that nothing better can be done, please don't worry. The Plasma, in my case, supports the ignition functioning with the surface discharge spark plugs, which:

                  1)Allow the use of the regular petrol 95 Ron instead of the super 98 Ron, without any compromise in the performance, (on the contrary, being immune to detonation and promoting a better combustion), the difference in Greece being ~ 20%.

                  2)Reduce the consumption, at least, (I give the official estimation), 6%.

                  3)Are susceptible to fouling if not supported by a proper, high energy, ignition, (here comes the Plasma).


                  Thank you for your time, (and knowledge).

                  Very happy with my Plasma.
                  Last edited by Hellenic Vanagon; 05-18-2018, 09:36 AM.
                  The Syncro Heresy

                  Comment


                  • (O.k., thinking about a water bubbler or a petrol fumes jar. Yes of course it works).



                    The Syncro Heresy

                    Comment


                    • just a quick post for a source for HV caps and diodes I've found:
                      hvstuff.com
                      they even have the HV wire discussed earlier in the thread

                      Comment


                      • Trying to do some updates to my system, tried modified spark plugs with the ground electrode removed, having that way a similar to the NGK BUE surface discharge spark plug operation with some differences:

                        #1 the central electrode now is 3 mm instead of 2 mm
                        #2 they look rather as semi-surface discharge, since the spark/arc is partially 180 on the ceramic insulator, (a tiny part), and the rest a free 360 spark/arc.
                        #3 the gap is now a huge 2 mm gap instead of the previous 1.3 mm, (recommended for the normal spark plugs is 0.7-0.8 mm), the 1.3 surface discharge gap being an easy for the sparc/arc to overcome because of that different geometry. (The distributor burns the contacts from the high energy demands, though, so it seems that the cavitated and filled with contactive grease contacts is a solution).

                        Now here is a question: with these modified spark plugs, sporadically, there is a strange phenomenon, (and this is why I am talking about spark and arc).

                        There are, simultaneously two discharges: one in a yellow-orange color, and 0.5 mm away, a second one with the bright white color. I thought that these two coincide always. Is this strange or it is expected?
                        Last edited by Hellenic Vanagon; 05-30-2018, 02:28 AM.
                        The Syncro Heresy

                        Comment


                        • Originally posted by Hellenic Vanagon View Post
                          Trying to do some updates to my system, tried modified spark plugs with the ground electrode removed, having that way a similar to the NGK BUE surface discharge spark plug operation with some differences:

                          #1 the central electrode now is 3 mm instead of 2 mm
                          #2 they look rather as semi-surface discharge, since the spark/arc is partially 180 on the ceramic insulator, (a tiny part), and the rest a free 360 spark/arc.
                          #3 the gap is now a huge 2 mm gap instead of the previous 1.3 mm, (recommended for the normal spark plugs is 0.7-0.8 mm), the 1.3 surface discharge gap being an easy for the sparc/arc to overcome because of that different geometry. (The distributor burns the contacts from the high energy demands, though, so it seems that the cavitated and filled with contactive grease contacts is a solution).

                          Now here is a question: with these modified spark plugs, sporadically, there is a strange phenomenon, (and this is why I am talking about spark and arc).

                          There are, simultaneously two discharges: one in a yellow-orange color, and 0.5 mm away, a second one with the bright white color. I thought that these two coincide always. Is this strange or it is expected?
                          Are you discharging plasma through a distributor? You can bypass it and go straight to the top of the plugs.

                          Are you a machinist? Perhaps you can try to make some Robert Krupa Firestorm plugs to test with the plasma.

                          Can you post a video or pic of the spark/arc?
                          Aaron Murakami





                          You never change things by fighting the existing reality. To change something, build a new model that makes the existing model obsolete. ― Richard Buckminster Fuller

                          Comment


                          • Originally posted by Aaron Murakami View Post
                            Are you discharging plasma through a distributor? You can bypass it and go straight to the top of the plugs.

                            Are you a machinist? Perhaps you can try to make some Robert Krupa Firestorm plugs to test with the plasma.

                            Can you post a video or pic of the spark/arc?
                            #1 The distributor is bypassed for the plasma, which is driven directly on the spark plugs, with tv cables.
                            #2 No, I haven't the equipment necessary to make them.
                            #3 I will try to catch the double discharges and I will post them.

                            Theoretically speaking, is it possible to have those two discharges in parallel, having between them a tiny distance, or they must coincide absolutely, as at 95% of the events happens ?
                            The Syncro Heresy

                            Comment


                            • Originally posted by Hellenic Vanagon View Post
                              #1 The distributor is bypassed for the plasma, which is driven directly on the spark plugs, with tv cables.
                              #2 No, I haven't the equipment necessary to make them.
                              #3 I will try to catch the double discharges and I will post them.

                              Theoretically speaking, is it possible to have those two discharges in parallel, having between them a tiny distance, or they must coincide absolutely, as at 95% of the events happens ?
                              I'll have to look at my old pics to see if I see them at the same time. Of course it is only possible for the cap to discharge after the HV normal spark jumps, but could be so fast the high current impulse from the cap jumps the gap before the spark is extinguished. That supports my belief in the accelerated discharge.
                              Aaron Murakami





                              You never change things by fighting the existing reality. To change something, build a new model that makes the existing model obsolete. ― Richard Buckminster Fuller

                              Comment


                              • Originally posted by Richard
                                TIG welding uses a tungsten electrode which can be purchased for $30 for 10 pieces (makes 20 sparkplugs?) of 1/8" diameter by 7" long.
                                Have you heard of anyone trying this material for the center electrode in the sparkplug?
                                Please look over this doc carefully: http://www.hho4free.com/spark%20plug...lasmaplugs.pdf
                                Aaron Murakami





                                You never change things by fighting the existing reality. To change something, build a new model that makes the existing model obsolete. ― Richard Buckminster Fuller

                                Comment
